NETRA-SOC Family Edge-AI Chips
| Platform Features | Platform Use Cases | Sensor Support | Chipset | CPU & SoC Features | Compression | Security | Connectivity |
|---|---|---|---|---|---|---|---|
|
CP-1000 |
CCTV platform with secure and advanced feature set |
5MP sensor |
Netra-C1000 |
ARM-A35, LPDDR4, MIPI CSI2, USB2, eMMC, ISP |
H264/H265/JPEG |
Trustzone, Secure features |
GiGE, WiFi,4G/5G |
| Platform Features | Platform Use Cases | Sensor Support | Chipset | CPU & SoC Features | Compression | Security | Connectivity |
|---|---|---|---|---|---|---|---|
|
AP-1020 |
Advanced CCTV camera with Built in AI (2 TOPS NPU) enabling content aware compression (CCA) |
5MP sensor |
Netra-A1020 |
ARM-A35, LPDDR4, MIPI CSI2, USB2, eMMC, NPU (2 TOPS), VPU, ISP |
H264/H265/JPEG |
Trustzone, Secure features |
GiGE, WiFi,4G/5G |
| Platform Features | Platform Use Cases | Sensor Support | Chipset | CPU & SoC Features | Compression | Security | Connectivity |
|---|---|---|---|---|---|---|---|
|
AP-2080 |
High-end Smart Traffic Camera platform with 8TOPS NPU(AI performance), CCA, HDR, Ultra low light features |
5MP / 4K |
Netra-A2000 |
ARM-A35(Quad), LPDDR4, MIPI CSI2 2×4, DSI, PCIe, eMMC, SATA, USB3 (super speed), NPU (8 TOPS), VPU, ISP with HDR. |
H264/H265/JPEG |
Trustzone, Secure features |
GiGE, WiFi,4G/5G |
| Platform Features | Platform Use Cases | Sensor Support | Chipset | CPU & SoC Features | Compression | Security | Connectivity |
|---|---|---|---|---|---|---|---|
|
APNV-40 |
AI-NVR/Edge Server for multi-camera AI
with 64 TOPs NPU(AI performance) |
Any |
Netra A4000 |
ARM-A35(Quad), LPDDR4, MIPI CSI2 2×4, DSI, PCIe,
eMMC, SATA, USB3 (super speed), NPU (64 TOPS),
VPU, ISP with HDR. |
H264/H265/JPEG
(Transcoder) |
Trustzone, Secure
features |
GiGE, WiFi,4G/5G |
NETRA SmartEdge Studio
AI Software Framework
NETRA-SOCs come with a powerful SDK, AI utilities, AI benchmark tools and a powerful Graph App builder that minimises the overall AI application development time using our chipsets. With the help of Graph builder tools one can enable complex heterogeneous acceleration engines to process the data in a graph stream pipeline with minimal or no coding effort. This not only helps to reduce the development time and faster market access, but also ensures best power-performance efficiency for the application. The Software framework supports AI development using models generated by standard libraries like Tensorflow, PyTorch, Caffe and ONNX. We also provide reference hardware kits and demo application suite for various target applications. Together with NETRA SmartEdge studio, SDKs, RDKs and demo suite, customers significantly reduce their time to market.
